Concrete Corrosion Mapping System by M.C. Miller
The M.C. Miller Concrete Corrosion Mapping System (CCMS) contains all equipment items that are needed to perform a corrosion survey on virtually all types of reinforced concrete structures, such as bridges, highway slabs and parking garages. The system can be used to satisfy the ASTM C-876 standard test method.
- LC-4.5 Voltmeter (Item #5203)
- Red, 6 ft Lead with 27-C (40 Amp) Clip (Item #33808)
- Black, 6 ft Lead with 27-C (40 Amp) Clip (Item #34903)
- Sponge Bottle Electrode - Copper Sulfate Version (Item #15625)
- RE-2.5U Electrode (Item #14905)
- Surfactant Solution, 4 oz (Item #15628)
- Anti-freeze Solution, 8 oz Bottle (Item #17105 )
- Copper Sulfate Crystals, 12 oz Bottle (Item #16906)
- 15 inch Intermediate Electrode Extension (Item #16200)
- Electrode Extension Adapter for LC-4.5 Voltmeter (Item #5701)
- Agra Reel with 250 ft #16 AWG Red Wire (Item #30510-250)
- 6 ft Banana Plug Test Lead (Item #34120)
- Pelican Carrying Case for CCMS (Item #CAS015)
- Foam Insert for CCMS Carrying Case (Item #CAS018)
Optional Accessories
Intermediate Electrode Extensions, 30" and 15" long. One or more can be used with MCM Model ETM, IA and LC series meters, or between the electrode and the standard electrode extension so that the electrode can be easily placed at the desire location inside manholes, water tanks, etc. Will fit through a 1" diameter augered hole.
#17105 - 8 oz #16906 - 12 oz # 30501
#17207 - 32 oz #17003 - 40 oz (wire supplied separately)
